AB-13121 Absima Torch 6S

Absima Torch 6S

The chassis is fully tuneable with adjustable ride height, tunable shocks, adjustable camber, adjustable toe angle, multiple shock mounting positions and adjustable rear wing.

Durable aluminum parts like the 3mm laser-engraved chassis plate, golden colored wheel hubs wishbone brackets, brace- and damper parts, ensure a long chassis life and a premium design
The drive concept - powered by HOBBYWING is top in it´s class for performance and reliability and accelerate the vehicle up to 110 km/h. The cooling fan on the 150A speed controller keeps temperatures consistent during full throttle 6S action. The 2100KV motor delivers insane power to the wheels.

The recommendations for the optional high-speed reduction (pinion is included in the scope of delivery) apply to operation on hard, level surfaces. Do not use for off-road, bashing or continuous start/stop riding, as this may damage the drive units (controller/motor)!

Parameters like brake force, drag brake, start mode (punch), running mode and LiPo cut-off you could change the settings through a set button or a programming box (separately available). T-plugs connectors provide a reliable connection between your speedo and your choosen battery packs. So much power want to be supplied! We advise to quality batteries with high capacity and a C-rate of at least 45C.

5.0mm CVD shafts front and rear, metal spur- and differential gears and 4.5mm center dogbones are used for power transmission.
"Easy-Use" motor mount concept for a quick and easy motor removal. Just open 2 screws and slide it out!
A high-speed pinion gear is included for high speed running on hard, flat surfaces. For off-road or high-load repetitive start-stop driving we recommend the standard pinion which is installed as standard!

Our proven ABSIMA "CR2SV2" 2.4 GHz radio system guarantees a fast and reliable connection to your vehicle. The 15kg metal gear servo with aluminum horn and durable high-performance tires ensure proper steering on any surface.

Features:

    Extremly durable composite plastic parts
    Monocoque suspension arms
    Fully adjustable chassis concept
    Hardened steel spur gear and motor pinion
    Adjustable oil-filled 16mm Aluminum Big Bore shocks
    3 full-metal geared differentials
    Downforce wing
    Adjustable wing holder
    2-piece sliding motor mount concept for easy adjustment and instalation
    Massive 5.0mm CVD axles - front & rear
    4.5mm middle steel drive shafts - front & rear
    Race compound low profile tires
    "Saddle-Pack" battery concept for a perfect weight distribution
    3mm black aluminum chassis plate with ABSIMA laser engravings
    Aluminum servo arm
    Seperate water- and dust-proof receiver box
    Completely ball bearing mounted
    Chassis sideguards for dirt protection
    All aluminum parts anodized in gold
    Aluminum 17mm wheel hex drives
    Steel turnbuckles all-over
    Adjustable camber, toe angle & ride height
    SPEED UP TO 110 KM/H

Electronics:

    ABSIMA "CR2SV2" 2.4GHz A.F.H.D.S. radio system (servo reverse and dual rate function; foam steering wheel)
    Water-proof 150A HOBBYWING speed controller (BEC: 6V/4A; programmable features: LiPo cut-off, runing mode, brake force, drag brake, punch)
    Powerfull 2100KV 4-pole sensorless brushless motor (600W, Shaft Ø: 5mm, Module 1)
    15kg / metal gear steering servo (25T outdrive) with aluminum servo arm

Specs:

    Scale: 1:8
    Drive type: 4WD
    Surface: Off-road
    Wheelbase: 375mm
    Chassis clearance: 45mm
    Tire width: 70mm
    Tire Ø: 145mm
    Steel motor transmission: Pinion: 13T / Spur gear: 49T
    Speed pinion included: Yes
    Pinion module: 1.0
    Length: 555mm
    Width: 445mm
    Height: 200mm
    Weight: 3970g (w/o batteries)

Required for Use:

    2x 11.1V LiPo batteries with XT60 plugs
    Suitable charger ask for details
    LiPo charging bag (Saftey)
    Optional programm box for easy setup (Item 2110041)
    4pcs. AA batteries for transmitter
