HW81020262 - XERUN SCT Pro Short Course Brushless Speedo - Black - 120A

XERUN SCT Pro Short Course Brushless Speedo - Black - 120A

Specification

1.1 Output: Continuous 120A, burst  760A;
1.2 Input: 6-12 cells NiMH/NiCd or 2-4S Lipo;
1.3 BEC: 6V/3A (Switching mode);
1.4 Resistance: 0.0004 Ohm;
1.5 Motor Supported: Sensored and sensorless brushless motor
1.6 Suitable Motor:
With 6 cells NiMH/NiCd or 2S Lipo:   KV<6000;
With 7-9 cells NiMH/NiCd or 3S Lipo:  KV<4000;
With 10-12 cells NiMH/NiCd or 4S Lipo:  KV<3000;
1.7 Suitable Car: 1/10 and 1/8 scale short course truck / buggy / tuggy;
1.8 Cooling fan: 5-6V;  Note #1
1.9 Size: 53.5mm(L) 36mm(W)  36mm(H).
1.10 Weight: 99g;

Note #1: The cooling fan is powered by the built-in BEC of 6V.

Features

 3.1 Sensored ESC and sensored motor have the best control feeling.
3.2 The switch mode BEC has powerful output to supply all electronic equipments.
3.3 Excellent start-up, acceleration and linearity features.
3.4 The major electronic components are sealed against splashing water or dust.
3.5 Plenty of programmable items, suitable for various of chassis's, tires and racing tracks.
3.6 Electric brake function, also compatible with mechanical disc-brake system.
3.7 Multiple protection features: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection.
3.8 Internal timing can be changed easily to make the ESC suitable for various of motors.
3.9 Easily programmed with the SET button, LED Program Box, Multifunction LCD Program Box and USB Link Software.
3.10 ESC firmware can be updated through the USB adapter in the LCD Program Box.
3.11 These is a mounting stand for installing the ESC on chassis easily and firmly.



Part No.: HW81020262
